Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner Sp/J-Bp2a-26CH
  • Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner Sp/J-Bp2a-26CH
  • Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner Sp/J-Bp2a-26CH
  • Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner Sp/J-Bp2a-26CH
  • Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner Sp/J-Bp2a-26CH
Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner Sp/J-Bp2a-26CH

Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner Sp/J-Bp2a-26CH

Certification CE, CCC, RoHS, GS, CB
Product Details
Model NO.:
SP/J-BP2A-26CH
Usage:
Room
Indoor Machine Noise:
39/34/32/30
China Energy Efficiency Standard:
Level 2
Cooling/Heating:
Cooling Only
Power Source:
Electrical
Power Type:
DC
Condition:
New
Rated Power Supply:
1pH / 220-240V/50Hz
Ation Temperature Range:
-7℃-43℃
Transport Package:
Carton
Specification:
R410A
Trademark:
HGI
Origin:
China
HS Code:
8415102100
Production Capacity:
500000/PCS Per Year
Highlight:

9000BTU wall mounted air conditioner

,

low-power inverter frequency air conditioner

,

wall hanging AC with warranty

Payment & Shipping Terms
Minimum Order Quantity
100
Price
280
Product Description
Fashionable Wall Mounted Air Conditioner Series 9000BTU Low-Power Operation Inverter Frequency Air Conditioner SP/J-BP2A-26CH
Product Description
DC INVERTER SP/J-BP2A-26CH SP/J-BP2A-35CH SP/J-BP2A-50CH SP/J-BP2A-70CH
Rated Power supply 1Ph / 220-240V/50Hz 1Ph / 220-240V/50Hz 1Ph / 220-240V/50Hz 1Ph / 220-240V/50Hz
Workable Power supply 1Ph / 150-260V/50Hz 1Ph / 150-260V/50Hz 1Ph / 150-260V/50Hz 1Ph / 150-260V/50Hz
Cooling Capacity (btu/h) 9000 12000 18000 24000
Capacity (W) 2500(150~3000)W 3200(150~3600)W 5100(1250-5910) 7100(1830~7800)
Input (W) 900(100~1200)W 1180(75~1560)W 1560(330-2340) 2260(410~2830)
Rated current (A) 4.0 (0.8~5.3)A 5.3(0.5~6.9)A 6.9(1.7~12.0) 10.1(2.3~12.3)
Pdesign (W) 2500 3200 5100 7100
EER 6.10 6.10 6.10 6.10
Heating Capacity (btu/h) 9000 12000 18000 24000
Capacity (W) 2800(150~3300)W 3400(150~3800)W 5100(1250-6070) 7100(1850~7900)
Input (W) 960(75~1260)W 1160(75~1580)W 1470(340-2520) 2040(420~3000)
Rated current (A) 4.3(0.5~5.6) 5.2(0.5~7.0)A 6.6(1.7~13.0) 9.1(2.3~13.5)
Pdesign (W) 2000 2100 3800 5000
COP 4.0 4.0 4.0 4.0
Max. input consumption (W) 1600 1720 2700 3200
Max. current (A) 8.00 9.00 13.00 15.80
Compressor Brand GMCC GMCC GMCC GMCC
Type Rotary Rotary Rotary Rotary
Indoor unit Indoor Coil Fin material Golden& hydrophilic& Golden& hydrophilic& Golden& hydrophilic& Golden& hydrophilic&
Tube outside dia.and material φ5mm, Inner Grooved φ5mm, Inner Grooved φ7mm, Inner Grooved φ7mm, Inner Grooved
Indoor air flow (Turbo/Hi/Mi/Lo) (M3/h) 500/450/370/320 550/500/450/370 850/750/650/580 1050/950/800/680
Rated input Power(cooling/heating) (W) 30 30 35 45
Rated current (cooling/heating) (A) 0.2 0.2 0.35 0.4
Moisture Removal (KG/h) 0.8 1.2 2 2.6
Noise level(Turbo/Hi/Mi/Lo) (dB(A)) 39/34/32/30 42/39/36/33 45/42/39/37 49/47/45/42
Unit dimension (W*H*D) 695*275*190 780*275*190 910*295*205 1075*330*240
Packing (W*H*D) 763*322*241 847*322*241 975*340*255 1146*412*318
Net weight (KGs) 6 7 11 15
Gross weight (KGs) 8 9 13 18
Outdoor unit Outdoor coil Fin material Golden& hydrophilic& Golden& hydrophilic& Golden& hydrophilic& Golden& hydrophilic&
Tube outside dia.and material φ7mm, Inner Grooved φ7mm, Inner Grooved φ7mm, Inner Grooved φ7mm, Inner Grooved
Noise level (dB) 50 52 55 59
Unit dimension (W*D*H) (mm) 710*295*495 710*295*495 780*350*600 850*385*700
Packing (W*D*H) (mm) 818*328*530 818*328*530 896*387*625 960*420*744
Net weight (KGs) 22 22 29 38
Gross weight (KGs) 25 25 33 42
Refrigerant type R32 R32 R32 R32
Refrigerant pipe Liquid side (mm) Φ6 Φ6 Φ6 Φ6
Gas side (mm) Φ9 Φ9 Φ12 Φ12
Max. refrigerant pipe length (m) 10 10 10 15
Max. difference in level (m) 5 5 5 10
Operation temperature range -7ºC-43ºC -7ºC-43ºC -7ºC-43ºC -7ºC-43ºC
Ambient temperature range -15ºC-48ºC -15ºC-48ºC -15ºC-48ºC -15ºC-48ºC
Application area (MM2) 10~17 13~27 20~40 30~55
Sets per 40ft HQ/20ft 40HQ/20 346/- 334/143 230/99 146/-
